Denon AVR-X6700H - Immersive Home Entertainment at Its Finest

Step into a world of unparalleled home theater entertainment with the AVR-X6700H. Boasting 8K/60Hz pass-through and upscaling, 4K/120Hz pass-through for gaming, and full support for the latest HDMI specifications, this AV receiver lets you create an exceptional 4K home theater experience now and guarantees 8K readiness for the future. Revel in top-tier 3D audio and video tailored to meet even the most discerning entertainment needs.

Powerful Amplification and Advanced Cinema Features

Delivering robust performance with 140 watts per channel (8 Ohms, 20Hz-20kHz, THD: 0.05%, 2 ch. driven), the AVR-X6700H ensures a dynamic and precise entertainment experience. Low impedance drivers maintain operational stability across a wide array of speakers, producing a well-balanced, tonal sound.

Elevate Your Experience with Dolby Atmos

Craft a 7.1.4 or 9.1.2 Dolby Atmos surround system using the eleven built-in channels. Pair it with Dolby Atmos elevation speakers or dedicated overhead speakers for an unparalleled Dolby home theater immersion. With Dolby Atmos Height Virtualization Technology support, enjoy immersive audio even without height channels, simulating virtual height effects within a 7.1, 5.1, or 2.1 speaker setup.

Next-Level Audio with DTS:X

Experience a revolution in audio with DTS:X and DTS Neural:X, transcending traditional 5.1ch surround sound for movies, games, and music. DTS Virtual:X Height Virtualization Technology support delivers immersive audio without dedicated height channels, replicating virtual height effects within a 7.1, 5.1, or 2.1 speaker arrangement.

DTS:X PRO - Future-Ready Surround Sound

With a forthcoming firmware update, unlock the potential of the latest DTS 3D audio technology. Revel in up to 13.2 channels of audio processing with DTS:X Pro, delivering a complete surround sound experience in intricate detail. Utilize an additional external stereo amplifier connected to the AVR-X6700H for two extra channels.

IMAX Enhanced Technology for Cinematic Brilliance

Explore cutting-edge IMAX Enhanced technology by DTS, setting a new standard for home theater in imaging, sound, scale, and clarity. Immerse yourself in sharper visuals and brighter images, coupled with heart-pounding audio, indulging in premium content digitally remastered by IMAX.

Auro-3D for a 3D Sound Experience

Enhance your home theater experience with Auro-3D, bringing three-dimensional sound to music, games, broadcasts, and films. Elevate your existing audio-visual collection with Auromatic up-mixing engine.

Future-Ready 8K HDMI Specs with Enhanced Audio Return Channel (eARC)

Featuring an advanced HDMI section (8 in/3 out) with a dedicated 8K input, the AVR-X6700H supports 8K/60Hz and 4K/120Hz video pass-through. All HDMI inputs support 4:4:4 Pure Color sub-sampling, HDR10, Dolby Vision, Hybrid Log-Gamma (HLG), 3D, and BT.2020 pass-through for unparalleled color, clarity, and contrast. Enjoy 8K upscaling and HDCP 2.3 processing for unrestricted playback of copy-protected content. eARC (enhanced Audio Return Channel) allows uncompressed and object-based audio transmission directly from smart TV apps to your AV receiver.

Advanced Video Controls for a Customized Experience

Every HDMI port supports HDCP 2.3 processing, ensuring seamless enjoyment of copy-protected content. Certified by the Imaging Science Foundation, the AVR-X6700H offers a comprehensive suite of video calibration controls, alongside ISF Day and ISF Night video modes. Seamlessly connect with the latest HD and Ultra HD TVs, Blu-ray players, and game consoles.

Vibrant Color for Stunning Visuals

The AVR-X6700H supports High Dynamic Range video formats including HDR10, Dolby Vision, and HLG (Hybrid Log Gamma). Revel in a transformed viewing experience with remarkable brightness, contrast, and color. HDR10+ delivers dynamic metadata to the TV for more authentic images, alongside Dynamic HDR.

JOSH.AI Smart Home Voice Automation

JOSH.AI, an advanced voice agent for upscale smart homes, offers versatile voice control over nearly every aspect of your daily routine and entertainment environment. Manage the thermostat, lighting, home appliances, speakers, AV receiver, and more through intuitive voice commands. JOSH.AI is expertly installed and easily accessed through an app on your iOS or Android device.

HEOS Built-In for Effortless Music Streaming

Experience your favorite music wirelessly in any room of your home with HEOS Built-in technology. Play the same track throughout every room or choose a different song for each connected room. HEOS supports a variety of streaming services including Spotify, Pandora, Amazon Music HD, TuneIn, SoundCloud, SiriusXM, TIDAL, and more.

High-Resolution Audio Support for Discerning Audiophiles

Featuring the latest AKM 32-bit D/A converters, the AVR-X6700H allows high-resolution audio decoding with multiple lossless file types including ALAC, FLAC, and WAV at up to 192kHz/24bit. Additionally, it supports 2.8/5.6-MHz DSD files (DSD is the audio coding format of SACD). Play these files from memory devices via the front panel USB or over network sources. The AVR-X6700H also accommodates other file types like MP3 and WMA.

Enhanced AL32 Processing for a Natural Soundstage

Enjoy advanced Denon audio processing features such as AL32 Processing, providing multi-channel ultra-high-resolution digital audio filtering on all audio channels. This technology delivers a natural soundstage and enhanced sound imaging.

DSP Audio Processing for an Immersive Sound Experience

Inherited from Denon's flagship AVR-X8500H, the AVR-X6700H incorporates a sophisticated digital audio processing system that includes two dual SHARC+ core DSP chips. This allows for up to 13 channel audio decoding and processing capability, including DTS:X Pro support and the introduction of 13 channel DTS:X reproduction (feature enabled via a future firmware update). Step into an immersive sound journey like never before.

These enhancements empower the Denon AVR-X6700H to deliver an unmatched and future-proof home entertainment experience. Whether you're a movie enthusiast, a gaming aficionado, or a music lover, this AV receiver elevates your audio-visual adventure to new heights. Dive into the magic of 8K-ready immersive entertainment and let your senses be captivated.

Denon AVR-X6700H Specifications

Multichannel Surround
- DTS HD Master / DTS:X / DTS:X Pro: Yes / Yes / Yes
- DTS Neo:X / DTS Neural:X: No / Yes

Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization
- Yes / Yes / Yes

Dolby ProLogic IIz / Dolby Surround
- No / Yes

Auro 3D
- Yes

Audyssey DSX
- No

Multichannel Stereo
- Yes

Max Number of Processing (Preamp) Channels
- 13.2

Sound Enhancements
- Mono Block Power Amp Construction: Yes
- Discrete Power Amplifier: Yes
- D.D.S.C. HD Digital: Yes (32 bit)
- Pure Direct: Yes
- Gold Plated RCA Terminals: Yes
- Clock Jitter Reducer: Yes
- Alpha Processing: Yes
- AL32 Processing Multichannel: Yes
- Denon Link HD: No
- Audyssey MultEQ XT32: Yes
- Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
- Audyssey LFC: Yes
- Compressed Audio Restorer: Yes

Network
- Media Server: Yes

Lossy Formats
- MP3 / WMA / AAC: Yes / Yes / Yes

Lossless Formats
- FLAC / ALAC / WAV: Yes / Yes / Yes

DSD Audio Streaming
- Yes (2.8/5.6MHz)

FLAC HD 192/24
- Yes

WAV 192/24
- Yes

ALAC 192/24
- Yes

Gapless playback
- Yes (FLAC, WAV, ALAC, DSD)

Photo Streaming (JPEG)
- No

AirPlay Audio Streaming
- Yes (AirPlay2)

Internet Radio
- Yes (TuneIn)

Spotify*
- Yes (connect)

Pandora
- Yes

SiriusXM
- Yes

Compatible with Remote APP for Smart Phones
- Denon 2016 AVR Remote: Yes

Ethernet Ports
- Yes

Wi-Fi
- Yes

Bluetooth
- Yes

HDMI
- HDMI Inputs: Back / Front: 7 / 1
- HDCP2.3 support: Yes
- HDMI Outputs: Main / Zone: 2 / 1
- Video Conversion Analog -> HDMI: Yes
- Analogue to HDMI scaling: Yes
- 480i/576i up to 8K 60/50: Yes
- HDMI to HDMI Scaling: Yes up to 8K 60/50
- GUI Overlay on HDMI: Yes
- 3D Signal Pass-through: Yes
- 8K signal pass-through / scaling / GUI overlay: Yes / Yes / Yes
- 4K Signal Pass-through / Scaling / GUI Overlay: Yes / Yes / Yes
- HDMI pass-through in standby mode: Yes
- Picture Adjust / Noise Reduction: Yes / Yes
- CEC: Yes
- DSD Audio Capability: Yes
- Audio Return Channel: Yes
- Auto LipSync: Yes

Multi-room CI
- Multiroom zones: 3
- Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
- Zone Audio Output: Speaker / Preout: Yes / Yes
- Zone HDMI Output from HDMI Source: Yes

IP Control / RS232 Control / Web Control / App Control
- Yes / Yes / Yes / Yes

Remote In / Out
- Yes / Yes

DC Trigger Output
- 2

Others
- Auto Speaker Setup by Microphone: Audyssey MultEQ XT32
- FL Display: 2 lines
- Graphic User Interface - GUI: Advanced
- ISF Certification: Yes
- GUI Languages: 3
- Setup Assistant: Yes
- Quick Select Plus / Quick Select: Yes / No
- Variable Crossover: Yes
- Optimized Bass Redirection: Yes
- Bass Sync: Yes
- ECO Mode: Yes
- Sleep Timer: Yes

Inputs Outputs
- Composite In / Out: 4 / 2
- Component In / Out: 2 / 1
- HDMI In / Out: 7+1 / 3
- Multi-room Video Out: Video / HDMI: Yes / Yes
- Analog In/out: 6 / No
- Phono (MM) In: Yes
- Digital In: Optical / Coaxial: 2 / 2
- Multi-room Out: Analog / Digital: 2 / No
- Multichannel Pre-out: Yes (11.2)
- Subwoofer Out: 2 (independent)
- 7.1 Multichannel Input: No
- Speaker Terminal: Gold Plated Screw / Regular Screw: Yes / No
- Number of Speaker Terminals: 13
- Speaker A / B: Assignable
- Bi-amp Drive: Assignable
- Multi-Room Speaker Terminal: Assignable

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB
- No / No / No / Yes / Yes

USB Audio / Made for iPod / Made for iPhone
- Yes / No / No

AM/FM Tuner
- Yes

Specifications
- Number of Power Amps: 11
- Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive): 140 W
- Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 175 W

General
- Metal Front Panel: Yes
- System Remote Control: RC-1240
- Pre-programmed / Learnable / LCD Display: Yes / No / No
- Power Consumption in W: 750
- Power Consumption No-Sound (ECO On / Off) in W: 65 W / 110 W
- Standby Consumption in W: 0.1
- CEC Standby Consumption in W: 0.5
- Network Standby Consumption in W: 3.5

Maximum Dimensions
- Antenna: Horizontal: (W x D x H) in Inches: 17.1 x 15.3 x 6.6
- Antenna: Vertical: (W x D x H) in Inches: 17.1 x 15.3 x 9.3
- W/O Antenna: (W x D x H) in Inches: 17.1 x 14.9 x 6.6

Weight in LBS
- 32
