All KLH Model Series Speakers - Model Seven, Model Five & Model Three Products
KLH Model Series Speakers with classic acoustic-suspension engineering, modern performance. Compare sizes, specs, and placement tips—and shop authorized with ListenUp expertise.
Models at a glance
Floorstanding · 3-way · 13" woofer
KLH Model Seven
Acoustic-suspension flagship with 13" woofer, 5" midrange, and 1" aluminum-dome tweeter
Three-position Acoustic Balance control for room tuning
Includes matte-black slant risers; finishes: English Walnut or West African Mahogany
Specs per speaker. Values summarized from KLH published materials.
Spec
Model Seven
Model Five
Model Three
System
3-way, acoustic-suspension
3-way, acoustic-suspension
2-way, acoustic-suspension
Drivers
1" alum-dome · 5" mid · 13" woofer
1" alum-dome · 4" mid · 10" woofer
1" alum-dome · 8" woofer
Frequency response (±3 dB)
38 Hz–20 kHz
42 Hz–20 kHz
46 Hz–20 kHz
LF extension (-10 dB)
26 Hz
32 Hz
35 Hz
Sensitivity (in-room / free-field)
91 / 88 dB
90.5 / 87.5 dB
88 / 85 dB
Power handling (RMS/peak)
250 / 1000 W
200 / 800 W
150 / 600 W
Recommended amp power
20–250 W
20–200 W
30–150 W
Dispersion (H)
—
140°
140°
Included base
Slant riser (≈3°)
5° slant riser
8° slant riser
Dimensions (with base)
41 × 18 × 12.25 in
34.25 × 13.75 × 13 in
28.25 × 12.25 × 11.5 in
Weight (with base)
78.8 lb
52 lb
36 lb
Finishes
English Walnut, West African Mahogany, Nordic Noir
English Walnut, West African Mahogany, Nordic Noir
English Walnut, West African Mahogany, Nordic Noir
What’s in the box
Speaker, grille, slant riser, manual
Speaker, grille, 5° riser, manual
Speaker, grille, 8° riser, manual
Looking for help choosing? Talk to ListenUp or book an in-store demo.
Which KLH Model is right for you?
Large rooms & big dynamics
Choose Model Seven
Deeper bass and higher output from the 13" woofer—perfect for larger spaces while keeping the tight, linear low end acoustic-suspension designs are known for.
Reference sound & value
Choose Model Five
The modern classic: 3-way clarity, room-tunable Acoustic Balance, and décor-friendly finishes.
Apartments & near-wall placement
Choose Model Three
Engineered to work closer to a wall or on a bookshelf than typical bass-reflex designs—ideal when space is tight.
How it works — quick setup tips
Start with the included riser angle (3° / 5° / 8°) to aim the tweeter toward ear height at the main seat.
Use Acoustic Balance to adapt for room gain or heavy furnishings—begin at Neutral, then try the other two positions.
Match your amplifier within the recommended power range for each model (see the table above) to preserve headroom and dynamics.
Optional subwoofer: set crossover near each speaker’s −3 dB point and adjust phase/level for seamless bass.
