Or the Music Hall MMF3.3 with more ListenUpgrades!
Power Supply: 15V / 0-0.8mA DC, universal power supply
Power Consumption: 4W / OW in stand-by
Speeds: 33⅓ rpm (manual change to 45 rpm)
Speed Deviation: ±0.18%
Wow and Flutter: ±0.11%
Rumble Max: -68 db
Effective Tonearm Length: 8.6 in.(218.5mm)
Overhang: .73"(18.5mm)
Dimensions: 16.75"W x 12.6"D x 4.33"H
Weight: 15 lbs.
Channel Balance at 1 kHz: 1.5 dB
Output Voltage at 1 kHz, 5cm/sec: 5.5 mV
Channel Separation at 1 kHz: 22 dB
Channel Separation at 15 kHz: 15 dB
Frequency Response: 20 Hz - 20 kHz (+3 dB / -1 dB)
Tracking Ability at 315Hz (Recommended Tracking Force): 70 µm
Compliance, Dynamic, Lateral: 20 µm/mN
Stylus Type: Elliptical
Stylus Tip Radius: r/R 8/18 µm
Tracking Force Range: 1.6-2.0 g (16-20 mN)
Tracking Force, Recommended: 1.8 g (18 mN)
Tracking Angle: 20°
Internal Impedance, DC Resistance: 1.3 kOhm
Recommended Load Resistance: 47 kOhm
Internal Inductance: 700 mH
Recommended Load Capacitance: 150-300 pF
