The Arcam AVR31 is a premium HDMI 2.1 Class G AV receiver with 16-channel Atmos/DTS:X/Auro-3D decoding and Dirac Live room correction. It supports 8K/60 and 4K/120 on every input plus HDR10+, Dolby Vision, HDR10, and HLG for cutting-edge video. Dual ESS 9026PRO DACs and seven channels of Class G power deliver low-noise, high-current musicality. Built-in Chromecast, AirPlay 2, Bluetooth aptX HD, Spotify/TIDAL Connect, MQA, and Roon Ready streaming complete the package.
Get the Details
Features & Specs
Cinematic 3D audio, 16 channels strong
Native decoding for Dolby Atmos, DTS:X, and Auro-3D means precise object-based placement and enveloping height effects across large speaker layouts.
Class G power with hi-fi pedigree
Seven channels of Arcam’s Class G topology (derived from their stereo amplifiers) deliver real-world current and low noise, preserving fine detail and dynamics. Arcam Next-gen HDMI 2.1 throughout – 7 inputs / 3 outputs with eARC, 8K/60 and 4K/120 support on every input, plus HDCP 2.3, keep you ready for the latest consoles and sources.
Room-tailored performance
Dirac Live is included to correct frequency and timing issues; Dirac Live Bass Control is available as a paid upgrade for multi-sub optimization.
Low-noise conversion – Dual ESS 9026PRO DAC
With reference voltage regulation deliver transparent, high-resolution playback.
All-in streaming & control
From Chromecast built-in and AirPlay 2 to Bluetooth aptX HD, Spotify Connect, TIDAL Connect, UPnP (MusicLife), plus MQA and Roon Ready, the AVR31 integrates effortlessly with modern ecosystems and custom control via Wi-Fi/Ethernet, RS232 and IR.
Native decoding for Dolby Atmos, DTS:X, and Auro-3D means precise object-based placement and enveloping height effects across large speaker layouts.
Class G power with hi-fi pedigree
Seven channels of Arcam’s Class G topology (derived from their stereo amplifiers) deliver real-world current and low noise, preserving fine detail and dynamics. Arcam Next-gen HDMI 2.1 throughout – 7 inputs / 3 outputs with eARC, 8K/60 and 4K/120 support on every input, plus HDCP 2.3, keep you ready for the latest consoles and sources.
Room-tailored performance
Dirac Live is included to correct frequency and timing issues; Dirac Live Bass Control is available as a paid upgrade for multi-sub optimization.
Low-noise conversion – Dual ESS 9026PRO DAC
With reference voltage regulation deliver transparent, high-resolution playback.
All-in streaming & control
From Chromecast built-in and AirPlay 2 to Bluetooth aptX HD, Spotify Connect, TIDAL Connect, UPnP (MusicLife), plus MQA and Roon Ready, the AVR31 integrates effortlessly with modern ecosystems and custom control via Wi-Fi/Ethernet, RS232 and IR.
Expert Insight
The Arcam AVR31 combines reference-grade sonics with bulletproof HDMI 2.1 connectivity, making it an easy recommendation for premium theaters. Dirac Live correction and dual ESS DACs yield a clean, controlled presentation with excellent dynamics. With robust streaming options and eARC, it functions as a modern hub that won’t bottleneck 8K or high-frame-rate gaming.
Nate M
Brand Manager
Details
Arcam AVR31 Flagship HDMI 2.1 Class G AV Receiver
16-channel decoding for Dolby Atmos, DTS:X, and Auro-3D.
Seven channels of high-power Class G amplification.
HDMI 2.1 on all inputs with 8K/60 and 4K/120; eARC; 7 in / 3 out (incl. Zone 2).
Dirac Live room correction with optional Bass Control upgrade.
Dual ESS 9026PRO DACs for audiophile-grade conversion.
Meet the Arcam AVR31 - a flagship HDMI 2.1 Class G AV receiver engineered for listeners who want concert-grade musicality and truly cinematic immersion at home. With native 16-channel decoding for Dolby Atmos, DTS:X, and Auro-3D, seven channels of high-power Class G amplification, and Dirac Live® room correction included, the AVR31 blends finesse and punch in equal measure. Next-gen video support - 8K/60 and 4K/120 on every input with HDR10+, Dolby Vision™, HDR10, and HLG - keeps your theater ready for premium sources and gaming. Streaming is instant via Chromecast built-in, Apple AirPlay 2, Bluetooth aptX HD, Spotify Connect, TIDAL Connect, UPnP (MusicLife app), plus MQA support and Roon Ready status, while dual ESS 9026PRO DACs deliver low-noise, high-resolution performance.
Arcam AVR31 Full Specifications:
Amplification: 7 channels of high-power Class G amplification
Decoding: 16 channels of Dolby Atmos, DTS:X & AURO-3D
HDMI: 7 inputs, 3 outputs (incl. Zone 2), eARC compatible; HDMI 2.1 with HDCP 2.3
Video support: All inputs support 8K@60fps and 4K@120fps; HDR10+, Dolby Vision, HDR10, HLG
Room correction: Dirac Live included; Dirac Live Bass Control (optional, license required)
DACs: Dual ESS 9026PRO with ESS reference voltage regulators
Networking & control: Wi-Fi / Ethernet, RS232, IR control
Streaming: Google Chromecast built-in, Apple AirPlay 2, Bluetooth aptX HD, Spotify Connect, TIDAL Connect, UPnP (MusicLife iOS/Android app)
Formats: Supports MQA; Roon Ready
Continuous power output per channel (8Ω/4Ω):
2 ch driven, 20Hz–20kHz, <0.02% THD: 120W / 200W
2 ch driven, 1kHz, 0.2% THD: 140W / 220W
7 ch driven, 1kHz, 0.2% THD: 100W / 180W
Residual noise & hum (A-weighted): <0.15mV
Stereo line inputs:
Max input: 4.5V RMS
Nominal sensitivity: 1V, 2V, 4V (user adjustable)
Input impedance: 47kΩ
S/N ratio (A-wtd, ref 100W) normal/stereo direct: 100dB / 110dB
Frequency response: 20Hz–20kHz ±0.2dB
Preamplifier outputs:
Nominal output level: 1V RMS (max 5V RMS)
Output impedance: 560Ω
THD+N (20Hz–20kHz): –100dB
Headphone output:
Max output level into 32Ω: 5V RMS
Output impedance: <100Ω
Mains voltage: 110–120V or 220–240V, 50–60Hz
Power consumption (max): 1.5kW (≈5200 BTU/hour)
Power consumption (idle, typical): 100W (≈350 BTU/hour)
How many HDMI connections does the AVR31 provide, and does it support eARC?
The AVR31 includes 7 HDMI inputs and 3 HDMI outputs, with eARC on the main output and a Zone 2 HDMI output.
Is the AVR31 compatible with 8K and high-frame-rate 4K gaming?
Yes—every input supports 8K/60 and 4K/120 with HDCP 2.3.
Which immersive audio formats are decoded natively?
Dolby Atmos, DTS:X, and Auro-3D are supported with native 16-channel decoding.
What room correction is included, and can I upgrade bass management?
Dirac Live is included; Dirac Live Bass Control is available via an additional license.
What streaming options are built in?
Chromecast built-in, Apple AirPlay 2, Bluetooth aptX HD, Spotify Connect, TIDAL Connect, and UPnP via the MusicLife app; supports MQA and is Roon Ready.
What DACs are used inside the AVR31?
Dual ESS 9026PRO DACs with ESS reference voltage regulators.
