Kaleidescape Strato M Movie Player
The Kaleidescape Strato M redefines entry-level with premium performance, delivering lossless Dolby Atmos audio and reference-quality 2K video in a compact, standalone package. Built for smaller spaces or secondary zones, the Strato M stores high-bitrate downloaded movies locally on a 480GB solid-state drive for flawless playback—without the limitations of streaming. Despite its compact size, it supports HDR10, Dolby Vision, and BT.2020 color, with multichannel support for Dolby TrueHD, DTS:X, and more. Easily scalable, Strato M can be grouped with a Kaleidescape Terra server and other players for a full-house, cinema-grade experience. Whether you're just starting with Kaleidescape or adding to your system, Strato M delivers exceptional quality, simplicity, and expandability.
What It’s Good At
- Delivering lossless audio for clearer dialog and more impactful, immersive surround effects
- Producing Blu-ray quality (or better) 2K output with advanced color support (Dolby Vision, HDR10, BT.2020, 4:2:2 chroma)
- Eliminating streaming artifacts with high-bitrate, locally downloaded movies (up to 100 Mbps)
- Working standalone with built-in SSD storage (ideal for a curated “top picks” library)
- Scaling into a multi-room system by adding Terra Prime servers and more Strato players
- Integrating cleanly into custom installs with silent, fanless operation and optional rack/wall mounting
Specifications
-
Model: Kaleidescape Strato M
-
Video Output: HDMI 2.1 with HDCP 2.3
-
Supported Video Resolutions: 1080p60/50/24, 1080i60/50, 720p60/50, 576i/p, 480i/p
-
HDR Formats: Dolby Vision (standard and low-latency), HDR10
-
Color Spaces: BT.2020, BT.709, BT.601
-
Chroma Subsampling: 4:4:4 8/10/12-bit, 4:2:2 12-bit
-
Aspect Ratios: 1.78:1 and 2.35:1 (CinemaScape)
-
Audio Output: HDMI 2.1 (audio + video)
-
Audio Formats: Dolby Atmos, DTS:X, Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, Linear PCM (up to 7.1ch, 96kHz/24-bit)
-
Internal Storage: 480GB SSD (approx. 6 high-bitrate Kaleidescape movies)
-
Networking: Gigabit Ethernet (1000 Base-T)
-
Control: IR receiver, Kaleidescape control protocol (Crestron, Control4, Josh.ai, etc.), Lutron RA3/HomeWorks
-
Power Consumption: Max 13W, Typical 4.3W, High standby 3.8W, Low standby 0.5W
-
Power Supply: 100–240VAC to 12VDC @ 5A, 60W (external adapter)
-
Environment: Operating 41–95°F (5–35°C), Max altitude 10,000 ft, Fanless operation
-
Mounting Options: Rack shelf and wall-mount (sold separately)
-
Dimensions (W × H × D): 6.4 x 1.1 x 6.4 in (16.3 x 3 x 16.3 cm)
-
Weight: 1.6 lbs (0.73 kg)
-
Certifications: CSA 62368-1, IEC 62368-1, FCC CLASS B, CE, RoHS
Expanded Key Features List
-
Lossless Audio Formats: Enjoy Dolby Atmos, DTS:X, Dolby TrueHD and more with true studio-quality sound for total immersion.
-
Reference-Quality 2K Video: Supports Dolby Vision, HDR10, and BT.2020 for exceptional visual performance in 1080p displays.
-
Standalone Design: Operates without a server, storing multiple high-bitrate movies locally with seamless playback.
-
High-Speed Downloads: Gigabit Ethernet enables movie downloads in just minutes with no buffering or compression loss.
-
Expandable System: Group with Terra servers and additional Strato players to scale across your entire home.
-
Compact, Silent Operation: Fanless design fits easily behind TVs or in racks, perfect for small rooms or secondary zones.
-
Smart Control Integration: Compatible with Crestron, Control4, Josh.ai, Lutron, and more for smart home integration.
-
Parental Controls & Child Mode: Unlock family-friendly features like child remote and custom content filters when grouped with a server.
Q&A Section
Q: What is the difference between Strato M and Strato E?
A: Strato M delivers reference-quality 2K video, while the Strato E offers 4K video. Both support the same lossless audio formats and can operate as standalone players or in a larger Kaleidescape system.
Q: Can Strato M play 4K movies?
A: Yes, it can play 4K files but outputs them in 2K resolution. It still preserves HDR10 and Dolby Vision color fidelity.
Q: How many movies can Strato M store?
A: With its 480GB SSD, it can hold about six Kaleidescape high-bitrate movies locally.
Q: Does Strato M require an internet connection?
A: Yes, for downloading movies and system updates. A gigabit Ethernet connection is recommended for optimal download speeds.
Q: Can I expand my setup later with more storage?
A: Absolutely. You can connect a Kaleidescape Terra server to expand your library and enable more players across your home.
Q: Is Strato M easy to install?
A: Yes, it’s compact and fanless—perfect for behind-the-TV installations or rack setups with optional mounting kits.
Q: Does it support smart home control systems?
A: Yes, it integrates with Josh.ai, Control4, Crestron, Lutron, and more using Kaleidescape’s control protocols.
Q: What happens when I run out of storage space?
A: Watched movies are automatically offloaded after 48 hours, but you can re-download them anytime without extra cost.
