- Output Power at 8Ω - 888 Watts (1.2HP)
- Output Power at 4Ω - 1776 Watts (2.4HP)
- Input Sensitivity - 2.4V RMS
- Input Impedance - 24KΩ
- Gain - 31dB
- Signal-to-noise Ratio - 120dB @ full power
- Frequency response (full range) - 10Hz - 200kHz +0/-3.0dB
- THD (20Hz - 20kHz @ full power) - 0.04%
- Intermodulation distortion - 0.006%
- Shipping weight - 300 lb / 136 kg
- Dimensions (width x height x depth)
22 x 14 x 27 in - 55.9 x 35.6 x 68.6 cm
- Massive single-piece cast aluminum heat sinks are manufactured using the same processes as high-performance racing engines.
- The heat sinks can dissipate energy far better than typical designs. Further CNC machining assures a fit & finish within 1/1,000”.
- Audio circuitry is integrated within the complex monolithic heat sink thereby dampening vibration down to the vanishing point.
- The transistors’ output section boasts a prodigious 8kW total rating, assuring the amplifier will always operates far below its capacity.
- Over 350,000μF of power supply energy storage and massive transformers for extreme power delivery.
- State-of-the-art componentry in all areas.
- All-aluminum chassis with cast and machined components assures exceptional heat dissipation and thermal efficiency.
- The finest rhodium-plated heavy-duty speaker output connectors.
The following accessories should be included inside the box with your power amplifier:
- AC power cable
- Owner’s manual
- Warranty and product registration information (USA and Canada only)
