NAD D 3020 V2 Hybrid Digital DAC Amplifier

The NAD D 3020 V2 Hybrid Digital DAC Amplifier brings classic NAD musicality into a modern, space-saving integrated amp built for today’s listening. Designed for desktop, TV, and compact hi-fi systems, it combines HybridDigital amplification with a high-resolution 24-bit/192kHz DAC to deliver clean detail, strong dynamics, and a balanced, engaging sound—even with real-world speakers in real rooms.

Connectivity is where the D 3020 V2 shines: stream wirelessly via Bluetooth with aptX, connect a TV or digital source through optical or coaxial inputs, and spin records with the built-in Moving Magnet phono stage featuring accurate RIAA equalization and infrasonic filtering. Performance tools like Bass EQ and soft clipping, plus a pre-out for adding a subwoofer or external amplification, make it easy to tailor your system for fuller sound and long-term listening comfort.

The NAD D 3020 V2 is part of ListenUp's NAD Music Streamer Collection.

What It's Good At:

• Big, confident sound in small systems with 30W/ch HybridDigital power and NAD PowerDrive™ for dynamic musical impact
• High-res digital playback up to 24-bit/192kHz for clear, detailed sound from computers and digital sources
• Wireless streaming done right with Bluetooth® + aptX® for improved quality and convenience
• Vinyl-ready performance via a dedicated MM phono input with RIAA equalization and infrasonic filtering
• TV and digital source upgrades using optical and coaxial inputs for cleaner dialogue and better clarity
• System expansion and tuning with pre-out for subwoofer/external amp plus Bass EQ and soft clipping for compact speakers

NAD D 3020 V2 Full Specifications:

• Rated Power at 8 ohms: 2 x 30 Watts
• IHF Dynamic Power (8 ohms): 2 x 60 Watts
• IHF Dynamic Power (4 ohms): 2 x 100 Watts
• IHF Dynamic Power (2 ohms): 2 x 150 Watts
• Signal/Noise Ratio (A-weighted, ref. 1 Watt): ≥90 dB
• Channel Separation (1 kHz): ≥75 dB
• Channel Separation (10 kHz): ≥65 dB
• Channel Balance: 0 ±0.3 dB
• Frequency Response (20 Hz – 20 kHz): 0 dB to -0.3 dB
• Total Harmonic Distortion: ≤0.005%
• Maximum input level: 5 V
• IMD (SMPTE): 0.02%
• IMD (CCIF): 0.003%
• MM Phono Input — Phono Signal-to-Noise Ratio: >82 dB (200 ohms source, A-weighted, ref. 500 mV out); 76 dB (MM cartridge source, IHF; A-weighted, ref. 500 mV out)
• MM Phono Input — Input sensitivity: 1.15 mV (ref. 500 mV out, Volume maximum)
• MM Phono Input — Maximum input signal at 1 kHz: >90 mVrms (ref. 0.1% THD)
• MM Phono Input — Frequency response: ±0.3 dB (20 Hz – 20 kHz)
• Standby Power: ≤0.5 Watts
• Supports bit rate/sample rate: up to 24/192 (via Digital Audio input)
• Unit Dimensions (W x H x D) Gross: 58 x 186 x 219 mm
• Net Weight: 1.38 kg (3.05 lb)
• Shipping Weight: 2.1 kg (4.6 lb)

NAD D 3020 V2 Q&A:

Does the D 3020 V2 work well for TV audio?

Yes. Use the optical or coaxial digital inputs to feed TV audio into the amp for clearer dialogue and more detailed sound through your speakers.

Can I stream music from my phone or laptop?

Yes. Bluetooth® with aptX® lets you stream wirelessly from compatible phones, tablets, and computers with improved audio quality.

Is this amplifier suitable for a desktop setup?

Absolutely. Its compact footprint is ideal for desks, studios, and small rooms while still delivering confident, high-fidelity power.

Can I connect a turntable directly to the D 3020 V2?

Yes—if your turntable uses a Moving Magnet (MM) cartridge. The built-in MM phono stage includes RIAA equalization and infrasonic filtering.

What is the maximum supported digital audio resolution?

It supports digital audio up to 24-bit/192kHz through the Digital Audio input for high-resolution playback.

Can I add a subwoofer?

Yes. The pre-out connection makes it easy to add a powered subwoofer (or external power amp) to expand low-end impact and system flexibility.

What do Bass EQ and soft clipping do?

Bass EQ helps add fullness—especially helpful with compact speakers—while soft clipping can make louder listening sound smoother and less harsh.

Is it energy-efficient?

Yes. It’s designed with low power draw in mind, including standby power consumption of ≤0.5 W.
