Kanto DM1 Single Monitor Desk Mount
DM1 Single Monitor Desk Mount is a spring-assisted aluminum monitor arm designed to create a cleaner, more ergonomic workspace for flat, curved, and ultrawide displays. It supports monitors from 17 to 40 inches and 4.4 to 22.1 pounds, with smooth fingertip height adjustment, up to 21.7 inches of reach, ±75° tilt, ±90° swivel, and full 360° rotation for easy portrait or landscape positioning. A top-mounted clamp simplifies installation from above the desk, while the quick-release VESA plate and integrated cable management make setup fast and keep your desktop organized. With durable aluminum construction, matte black or white finishes, and included clamp or grommet mounting hardware, the DM1 is built for everyday productivity, gaming, and creative work.
What It's Good At:
- Supporting flat, curved, and ultrawide monitors from 17" to 40" with stable spring-assisted performance.
- Delivering ergonomic monitor placement with up to 9.5" to 9.9" of height adjustment and up to 21.7" of reach.
- Making positioning easy with ±75° tilt, ±90° swivel, and 360° screen rotation.
- Speeding up installation with a top-of-desk clamp and included grommet hardware for a wide range of desk setups.
- Simplifying monitor setup through a detachable quick-release VESA plate.
- Keeping workstations clean and modern with integrated cable management and durable aluminum construction.
Kanto DM1 Full Specifications:
- Product name: DM1
- Product type: Single Monitor Desk Mount / Single Monitor Arm
- Category: Desktop Monitor Mounts
- Supported screen sizes: 17" to 40"
- Supported monitor types: Flat, curved, and ultrawide monitors
- Weight capacity: 4.4 lb (2 kg) to 22.1 lb (10 kg)
- Max loading weight noted in manual: 22 lb (10 kg)
- VESA compatibility: 75 x 75 mm and 100 x 100 mm
- Height adjustment: 9.5" on product page; 9.9" (25.1 cm) on product sheet
- Reach: Up to 21.7" (55.1 cm)
- Tilt: ±75°
- Swivel: ±90°
- Rotation: 360°
- Screen orientation support: Portrait and landscape
- Installation methods included: Desk clamp and grommet mount
- Desk clamp thickness range: 0.4" to 2.0" (10 to 50 mm)
- Grommet thickness range: 0.4" to 2.0" in manual; product page states 0.4" to 2.2"
- Top-mount installation: Yes
- Quick-release VESA plate: Yes, detachable
- Cable management: Integrated cable management / cable clips included
- Materials: Aluminum construction with durable painted finish
- Finishes / color options: Matte black (DM1) and white (DM1W)
- Product dimensions (W/D/H): 55 x 10 x 54.5 cm (21.7" x 3.9" x 21.5")
- Product weight: 2.6 kg (5.6 lb)
- Shipping box dimensions (W/D/H): 41.8 x 15.7 x 13.4 cm (16.5" x 6.2" x 5.3")
- Shipping box weight: 3.3 kg (7.3 lb)
- Base width shown on technical drawing: 11 cm (4.3")
- Height shown on technical drawing: 47.6 cm (18.7")
- Lower height shown on technical drawing: 22.5 cm (8.9")
- Warranty: 5-year manufacturer’s warranty
- Included in the box: Clamp and grommet mounting hardware, assembly manual, and monitor mounting hardware
- UPC: 800152725987 (Black); 800152726083 (White)
Kanto DM1 Q&A:
- What size monitors does the Kanto DM1 support?
- The DM1 is designed for monitors from 17 to 40 inches, including flat, curved, and ultrawide displays.
- How much weight can the DM1 hold?
- It supports monitors weighing from 4.4 lb (2 kg) up to 22.1 lb (10 kg), with the manual listing a 22 lb maximum load.
- Which VESA patterns are compatible with this monitor arm?
- The DM1 works with 75 x 75 mm and 100 x 100 mm VESA mounting patterns.
- How adjustable is the DM1 for ergonomic positioning?
- It offers spring-assisted height adjustment, up to 21.7 inches of reach, ±75° tilt, ±90° swivel, and 360° rotation for portrait or landscape viewing.
- Does the DM1 install with a clamp or a grommet mount?
- Both options are included. The mount ships with desk clamp and grommet hardware to fit a wide range of desk setups.
- Is installation difficult under the desk?
- No. One of the DM1’s standout features is its top-mount clamp design, which tightens from above the desk for faster, easier installation.
- Does it help keep cables organized?
- Yes. The DM1 includes integrated cable management clips to route cables neatly and reduce desktop clutter.
- What comes in the box with the DM1?
- The package includes clamp and grommet mounting hardware, monitor mounting hardware, and the assembly manual.
Kanto DM1 Downloads:
Kanto DM1 Manual
Kanto DM1 Product Sheet
Kanto DM1 Drawing
